Introduction to Radiographic Assessment

Radiographic evaluation plays a pivotal role in the diagnosis and management of impacted teeth. It provides essential information about the position, angulation, and relationship of impacted teeth to surrounding anatomical structures. This knowledge is frequently tested in NEET previous year question papers and is fundamental for clinical practice.

Radiographic Techniques for Impaction Assessment

Conventional Radiography

Intraoral Periapical Radiographs (IOPA)

• Application: Provides detailed view of the impacted tooth and adjacent structures
• Advantages: High resolution, readily available, low radiation dose
• Limitations: Limited field of view, superimposition of structures
• Technique: For mandibular third molars, a slight distal angulation helps visualize the entire tooth

Panoramic Radiographs (OPG)

• Application: Comprehensive view of all teeth, jaws, and surrounding structures
• Advantages: Wide field of view, visualization of bilateral structures, patient comfort
• Limitations: Magnification, distortion, lower resolution than IOPA
• Significance: Often the initial radiograph of choice for impaction assessment

Occlusal Radiographs

• Application: Determine buccolingual position of impacted teeth, especially maxillary canines
• Advantages: Wide coverage, different perspective from IOPA
• Techniques:
  • Maxillary Occlusal: Vertex occlusal, occipitomental
  • Mandibular Occlusal: Standard occlusal, cross-sectional occlusal

Advanced Imaging Techniques

Cone Beam Computed Tomography (CBCT)

• Application: Three-dimensional assessment of impacted teeth
• Advantages: Precise localization, visualization of adjacent structures, elimination of superimposition
• Indications: Complex impactions, suspected root resorption, proximity to vital structures
• Significance: Particularly valuable for maxillary canine impactions and complex third molar cases

Computed Tomography (CT)

• Application: Detailed evaluation of bone and soft tissue
• Advantages: High-resolution images, multiplanar reconstruction
• Limitations: Higher radiation dose, cost
• Indications: Complex cases requiring detailed assessment of vital structures

Radiographic Assessment of Mandibular Third Molar Impactions

Key Radiographic Features to Evaluate

1. Angulation of impacted tooth (Winter's classification)
2. Relationship to the mandibular ramus (Pell & Gregory classification)
3. Depth relative to occlusal plane (Pell & Gregory position)
4. Root morphology: Number, shape, and curvature of roots
5. Proximity to inferior alveolar canal
6. Presence of pathological conditions: Cysts, tumors, caries
7. Condition of adjacent second molar
8. Density of surrounding bone

Predicting Inferior Alveolar Nerve Injury: Rood and Shehab Classification

Radiographic signs that predict potential injury to the inferior alveolar nerve during third molar extraction:

Root-Related Signs

• Darkening of the Root: Radiolucent band when the canal is superimposed on the root
• Deflected Roots: Buccal, lingual, or mesiodistal deviation at the canal crossing point
• Narrowing of the Root: Sudden constriction where the canal crosses the root
• Dark and Bifid Root Apex: Double periodontal membrane shadow visible when the canal crosses the root apex

Canal-Related Signs

• Interruption of White Line: Discontinuity of the radiopaque borders of the canal
• Diversion of Canal: Upward displacement of the canal by the roots
• Narrowing of Canal: Reduction in diameter where it crosses the root apex

Clinical Significance: The presence of these signs significantly increases the risk of nerve injury during extraction, warranting modified surgical techniques or referral to specialists.

Bull's Eye Appearance

A distinctive radiographic sign where the root of the impacted tooth appears as a radiolucent circle with a central radiopaque dot, indicating that the tooth is lingually positioned.

Radiographic Assessment of Maxillary Canine Impactions

Localization Techniques

Clark's Rule (SLOB Rule)

• Principle: Same Lingual, Opposite Buccal
• Technique: Two radiographs taken at different horizontal angulations
• Interpretation: Object that moves in the same direction as the tube shift is lingually positioned; object that moves in the opposite direction is buccally positioned

Buccal Object Rule

• Principle: Objects located buccally move in the opposite direction to the tube shift
• Application: Particularly useful for maxillary canine localization

Parallax Technique

• Principle: Similar to Clark's rule but using vertical angulation changes
• Application: Useful when horizontal shifts are difficult

Specific Radiographic Signs for Maxillary Canines

1. Sector Location: Position of the canine crown relative to the lateral incisor root
2. Vertical Height: Distance from the occlusal plane
3. Angulation: Orientation of the long axis relative to adjacent teeth
4. Root Development: Stage of root formation
5. Overlap with Adjacent Teeth: Degree of superimposition

Difficulty Assessment Using Radiographs

WAR LINES

Winter’s WAR lines are a set of three imaginary lines drawn on an intraoral periapical radiograph (IOPA) or orthopantomogram (OPG) to assess the position and depth of an impacted mandibular third molar in relation to the second molar and mandibular bone. They are used preoperatively to estimate the difficulty of surgical extraction.

 W - White Line

• Drawn along the occlusal surfaces of the erupted mandibular molars and extended posteriorly over the third molar region.
• Represents the occlusal plane.
• Purpose: To assess the level of eruption of the third molar relative to the adjacent teeth.
• Clinical relevance:
  • If the occlusal surface of the third molar is at or near this line, eruption is nearly complete.
  • If below, impaction is deeper and more complex.

🔹 A - Amber Line

• Drawn from the alveolar crest distal to the second molar to the crest of bone over the impacted third molar.
• Represents the height of alveolar bone overlying the impacted tooth.
• Clinical relevance:
  • Helps determine the amount of bone removal required during surgery.
  • The deeper the amber line lies, the more bone has to be removed, increasing surgical difficulty.

🔹 R - Red Line

• A perpendicular line dropped from the occlusal surface (white line) down to the point of application of the elevator on the impacted third molar.
• Purpose: Assesses depth and accessibility for applying elevators.
• Clinical relevance:
  • The longer the red line, the more difficult it is to extract the tooth due to:
    • Deeper impaction
    • Limited access for instruments

WHARFE Assessment

This comprehensive scoring system evaluates:

• W: Winter's classification (angulation)
• H: Height of the mandible
• A: Angulation of the third molar
• R: Root shape and development
• F: Follicle development
• E: Exit path availability

Clinical Significance: Higher scores indicate greater extraction difficulty.

Pederson Difficulty Index

Assigns values to spatial relationship, depth, and ramus relationship to predict extraction difficulty.

Pre-Surgical Radiographic Planning

Essential Measurements

1. Distance to Inferior Alveolar Canal: Critical for avoiding nerve damage
2. Thickness of Overlying Bone: Determines bone removal requirements
3. Proximity to Adjacent Teeth: Evaluates risk of damage
4. Angulation and Position: Guides surgical approach and tooth division needs

Radiographic Markers of Surgical Complexity

1. Hypercementosis: Excessive cementum deposition making extraction difficult
2. Ankylosis: Fusion of tooth to bone, visible as absence of periodontal ligament space
3. Dilacerated Roots: Severe curvature increasing fracture risk
4. Proximity to Vital Structures: Mandibular canal, mental foramen, maxillary sinus

Radiographic Assessment for Post-Extraction Complications

Key radiographic findings that may indicate complications:

1. Retained Root Fragments: Radiopaque structures in the socket
2. Displacement into Anatomical Spaces: Maxillary sinus, mandibular canal, submandibular space
3. Fracture Lines: Radiolucent lines in the mandible
4. Oro-Antral Communication: Discontinuity of the sinus floor

Conclusion

Proficient radiographic assessment is indispensable for the successful management of dental impactions. As a dental student preparing for NEET MDS, mastering these techniques and interpretation skills will enhance your diagnostic abilities and treatment planning.
